12V 200W Blanket Solar Panel with Accessories

12V 200W Blanket Solar Panel with Accessories

  • CAT.NO: ZM9124
On special
$249.00$459.00
Save $210.00Hurry! Offer expires in 11 days

Store

Choose a store for stock availability
12V 200W Blanket Solar Panel with Accessories
$249.00
1 Year Warranty

Blanket solar panels are much lighter and take up less space compared to traditional fold-up solar panels. This 12V 200W solar panel weighs just 6.1kg and when not in use, it folds down to just 560mm wide by 390mm high, small enough to easily stow away in a storage cupboard. When you want to use it, simply unfold and lay on the ground or across your car’s windscreen and connect the pre-fitted 4.5 metre extension lead via the high current connectors to your battery system. A charge controller is included, so you can connect directly to lead acid batteries without any additional hardware. The charge controller also includes a USB charging outlet, perfect for charging mobile phones in an emergency. Supplied with a built-in pouch for accessory storage.

Not intended for permanent outdoor installation.

Features:

  • High efficiency MPPT charge controller
  • Includes pre-installed High Current connectors
  • Compatible with 12V Flooded, Lead, AGM & GEL Batteries
  • Durable cover with carry handle
Solar Panel

Solar panel type

Monocrystalline

Mounting Method

Folding Portable

Open Circuit Voltage

24.7 V

Short Circuit Current

9.06 A

Voltage at Power Max

20.1 V

Current at Power Max

8.5 A

Power Rating

Continuous Power

200.0 W

Product Dimensions

Width

1170.0 mm

Height

1120.0 mm

Weight

5.8 kg

Dimension details

Solar Panel Dimensions - Unfolded

Additional Dimensions

Width

131.0 mm

Height

99.5 mm

Depth

29.5 mm

Weight

300.0 g

Dimensions details

Charge Controller Dimensions

Internal or Sub-part Dimensions

Width

560.0 mm

Height

390.0 mm

Dimension details

Solar Panel Dimensions - Folded

Solar Charge Controllers and Regulators

Max Charging Current

20.0 A

Max Load Current

20.0 A

Charge Controller Technology

Maximum Power Point Tracking (MPPT)

Packaged Dimensions

Packaged Dimensions

59.0cm(Length) x 12.3cm(Width) x 41.6cm(Height)
